electronic differential lock (EDL) (English, Русский)

what is an electronic differential lock (EDL)?

Electronic Differential Lock (EDL) is a limited slip differential imitation - this is an electronic system that detects wheelspin via ABS sensors and applies brakes to spinning wheels. This results in the torque being transferred via open differentials to another wheel that has more traction.

For example, the system brakes the wheel that is raised in the air and spinning freely, and engine power goes to another wheel that is on the ground.

See how electronic differential lock works in our Videos section.

Pin Do you think this information about What Is An Electronic Differential Lock (Edl)? is incomplete? Please send us what you know to or leave a comment below.

This is a Wiki, so feel free to correct any factual or grammatical error. Test here before posting.

There are 5 comments
Chris
February 08, 2024 - 22:49

I have a 2004 cadillac ext awd and the front cv shaft broke but the truck will not stop when placed into park.... does that mean the rear axle is not working and only the front axle is pulling ???i have no idea how to understand that the rear axle doesnt lock when the trans is placed into park

santaji
July 01, 2014 - 12:03

JLR Defender new all wheel drive arrangement?

RAMEEZ NAQvi
August 16, 2013 - 19:58

What about freelander 1 Td4 2006............

Ernesto Lopez
December 04, 2011 - 00:12

It Does any conection among ABS and any problem with Transfer?

Reply to Ernesto Lopez
George
December 21, 2011 - 21:31

MB used such a system in the original ML-class SUV.
MB wrote that overheating was a potential problem.
The brake hardware can overheat, so a computer model is utilized to calculate expected brake temperature. Therefore a safe reserve can be programmed in.
Also the ABS hardware can overheat, though MB says it will take two minutes of continuous operation to do so.
